Yamaha CZR10 Passive Speaker

54,950.00

Description

Killer Sound, Top Performance, and Easy System Integration

The Yamaha CZR10 offers superb clarity and best-in-class SPL performance. This 2-way bi-ampable PA speaker boasts 1,400-watt power handling, a 43Hz-20kHz frequency range, and can tackle any application you throw at it. Great-sounding, custom-designed transducers deliver vivid, soaring highs and rafter-shaking low end. As a passive PA speaker, the CZR10 integrates with any configuration, thanks to its rotatable horn. It can also operate effectively as a stage monitor. This speaker can take full advantage of processor tuning settings when used with a Yamaha PX Series amplifier.

Features

Yamaha CZR10 Features:

  • 2-way passive loudspeaker with 2″ HF and 10″ LF drivers
  • Boasts 1,400-watt power handling and bi-amp capabilities
  • 43Hz-20kHz frequency range with 127dB SPL
  • Great-sounding, custom-designed transducers
  • Rotatable horn allows vertical or horizontal mounting
  • 90×60° dispersion from a vertical position
  • Constant directivity horn supplies smooth, level coverage without roll-off
  • Compatible with Yamaha PX Series amplifier processor tuning settings (amplifier sold separately)
  • Lightweight, yet durable, plywood cabinet with a premium-grade polyurea coating

Specifications

  • Powered: No
  • Power Configuration: 2-way Passive/Bi-amped
  • LF Driver Size: 10″ Woofer, 3″ Voice Coil with Neodymium Magnet
  • HF Driver Size: 2″ HF Compression Driver
  • Impedance: 8 ohms
  • Power Rating: 700W Program
  • Total Power: 1400W Peak
  • Inputs: 2 x SpeakON (parallel)
  • Frequency Range: 43Hz-20kHz (passive), 46Hz-20kHz (with DSP processing)
  • Crossover Frequency: 2.5kHz
  • Maximum Peak SPL: 127 dB SPL @ 1m
  • Horizontal Coverage Angle: 90 Degrees
  • Vertical Coverage Angle: 60 Degrees
  • Enclosure Material: Plywood Cabinet with Polyurea Coating
  • Mounting Options: Pole: 2 x 1.37″ (35mm); Fly: 8 x M10, 2 x M8; Wedge
  • Height: 21.1″ (with feet)
  • Width: 12.4″
  • Depth: 13.6″
  • Weight: 30.9 lbs.
