Yamaha DXS15XLF Powered Subwoofer

119,950.00

Description

Sophisticated DSP processing

At Sweetwater, we’re impressed by the DXS15XLF’s intelligent DSP processing. Yamaha’s D-XSUB LF processing gives you total command of your low end. Choose between a NORMAL mode that offers balanced low-frequency response and a BOOST mode that provides tighter, more focused bass with extra punch. Beyond that, XTENDED LF mode drops your low-end even lower, yielding chest-thumping low-frequencies that must be heard to be believed. Ensure a clean stage monitoring environment, thanks to the DXS15XLF’s Cardioid Mode, which effectively decreases the sound pressure onstage while increasing the low-frequency output directed towards your audience. Despite all this powerful DSP, the DXS15XLF remains easy to use, thanks to optimized factory presets and an intuitive LCD screen.

Features

Yamaha DXS15XLF Features:

  • Powered subwoofer with 15″ LF driver
  • A must-have for completing your full-range DZR system
  • Boasts a high-power 1,600-watt Class D amplifier and 33Hz–150Hz frequency range
  • D-XSUB LF processing gives you total command of your low end with NORMAL, BOOST, and XTENDED LF modes
  • Cardioid Mode decreases stage volume while increasing the low-frequency output directed towards your audience
  • Optimized factory presets and intuitive LCD screen make operation easy
  • Great-sounding, custom-designed transducer
  • Dual damper ensures extraordinary low-frequency linearity during high-output situations
  • Lightweight, yet durable, plywood cabinet with a premium-grade polyurea coating

Specifications

  • Powered: Yes
  • LF Driver Size: 15″ Cone, 4″ Voice Coil, Ferrite Magnet
  • Power Rating: 1230W Continuous
  • Total Power: 1600W Peak
  • Inputs: 2 x XLR-1/4″ combo
  • Outputs: 2 x XLR (thru/output)
  • Other I/O: 1 x USB Type A
  • Frequency Range: 33Hz-150hz (-10 dB)
  • Maximum Peak SPL: 136dB SPL @ 1m
  • Signal Processing: EQ, Delay, Cardioid Mode, D-XSUB Processing
  • Mounting Options: Floor, Pole Mount with 1.37″ (35mm) and M20 sockets
  • Power Source: Standard IEC AC cable
  • Enclosure Material: Plywood Cabinet with Polyurea Coating, Black Finish
  • Height: 23.1″
  • Width: 17.7″
  • Depth: 23.6″
  • Weight: 88.2 lbs.
